Discover the 0805G470KTE Capacitor by STETCO: Features, Applications & Technical Insights

The 0805G470KTE capacitor STETCO SMD0805 stands out as a multilayer ceramic capacitor designed in the SMD0805 package. Engineers use this component for filtering, decoupling, and timing in electronic circuits. This model meets RoHS standards, ensuring environmental safety. Its compact size and reliable construction make it ideal for modern devices. The 0805G470KTE STETCO offers consistent performance where space and compliance matter most.

Key Takeaways

• The 0805G470KTE capacitor by STETCO is a small, reliable multilayer ceramic capacitor ideal for compact circuit boards.

• It offers 47nF capacitance and supports up to 50 volts, making it suitable for filtering, bypassing, and decoupling in many devices.

• This capacitor meets RoHS and halogen-free standards, ensuring it is safe for the environment and modern manufacturing.

• Engineers use it widely in consumer electronics, industrial systems, automotive circuits, medical devices, and IoT applications.

• Proper placement and handling of the capacitor on PCBs improve performance and prevent damage during assembly.

Key Features

Package & Design

The 0805G470KTE capacitor STETCO SMD0805 uses the industry-standard SMD0805 package. This package measures approximately 2.0 mm by 1.25 mm, making it suitable for compact circuit boards. The multilayer ceramic construction provides stable electrical performance and high reliability. Engineers often choose this model for its nickel-barrier end terminations. These terminations help prevent solder leaching during assembly and improve long-term durability. The halogen-free status of this capacitor supports safer and more environmentally friendly electronics.

Tip: The SMD0805 package allows for high-density mounting on modern PCBs, which helps designers save valuable board space.

Capacitance & Voltage

This capacitor offers a capacitance value of 47 nanofarads (nF). The 47nF rating makes it ideal for signal filtering, bypass, and decoupling tasks in electronic circuits. The 0805G470KTE capacitor STETCO SMD0805 supports a maximum working voltage of 50 volts. This voltage rating covers both low-voltage and moderately high-voltage applications. The multilayer ceramic design ensures stable capacitance across a wide range of frequencies and temperatures.

RoHS & Safety

STETCO manufactures this capacitor to meet strict RoHS standards. RoHS compliance means the product contains no hazardous substances like lead, mercury, or cadmium. The halogen-free status further reduces environmental impact. The 0805G470KTE capacitor STETCO SMD0805 comes in tape and reel packaging, which supports automated surface-mount technology (SMT) assembly. This packaging method ensures consistent quality and reduces handling errors during production.

Note: RoHS compliance and halogen-free materials make this capacitor a responsible choice for manufacturers who prioritize environmental safety.

Specifications

Electrical Parameters

The 0805G470KTE capacitor STETCO SMD0805 delivers precise electrical performance. It has a capacitance value of 47 nanofarads (nF). This value helps stabilize voltage and filter signals in electronic circuits. The rated voltage stands at 50 volts (V), which supports both low and moderately high-voltage applications. The capacitor offers a tolerance of ±10%. This means the actual capacitance can vary by 10% above or below the stated value. The device uses a Class II dielectric material, which provides stable performance over a wide temperature range.

Note: High insulation resistance and low dissipation factor ensure reliable operation in sensitive circuits.

Physical Dimensions

The SMD0805 package defines the physical size of this capacitor. The numbers "0805" refer to its dimensions in inches: 0.08 inches long and 0.05 inches wide. In metric units, this equals about 2.0 mm by 1.25 mm. The height usually measures around 0.85 mm. The compact size allows engineers to place many capacitors on a single printed circuit board (PCB). The device uses nickel-barrier end terminations. These terminations improve solderability and prevent damage during assembly.

The small footprint of the SMD0805 package supports high-density circuit designs.

Performance

STETCO designs this capacitor for consistent and reliable performance. The multilayer ceramic structure resists cracking and mechanical stress. The device meets strict quality standards, including RoHS compliance and halogen-free certification. These certifications show that the capacitor contains no hazardous substances and supports environmental safety. The 0805G470KTE capacitor STETCO SMD0805 passes rigorous reliability tests, such as temperature cycling and humidity resistance. It maintains stable capacitance across a wide temperature range, from -55°C to +125°C. This stability ensures dependable operation in consumer, industrial, and automotive electronics.

Engineers trust this capacitor for its proven reliability and compliance with international safety standards.

Applications

Consumer Electronics

The 0805G470KTE capacitor STETCO SMD0805 plays a key role in many consumer electronics. Engineers use this component in televisions, set-top boxes, smart speakers, and headphones. These devices require stable signal filtering and noise suppression. The capacitor helps maintain clear audio and video signals. Its compact size allows designers to fit more features into smaller products. Tape and reel packaging supports automated assembly, which increases production speed and consistency.

Note: Reliable capacitors help prevent unwanted noise and signal drops in home entertainment systems.

Industrial & Automotive

Industrial automation and automotive electronics demand high reliability. This capacitor supports automation controls, sensors, and meters. In vehicles, it works in dashboard circuits and infotainment modules. The 50V rating ensures safe operation in circuits that experience voltage spikes. The capacitor’s multilayer ceramic design resists vibration and temperature changes. Engineers trust it for long-term stability in harsh environments.

• Typical industrial uses:

  • Factory sensors

  • Metering equipment

  • Control panels

• Automotive applications:

  • Dashboard displays

  • Audio systems

  • Navigation units

Power, Medical & IoT

Power management circuits rely on stable capacitors for DC-DC converters and voltage regulators. The 0805G470KTE model provides effective bypass and decoupling, which reduces voltage fluctuations. Medical devices, such as portable monitors and diagnostic tools, benefit from its small size and reliability. In the IoT sector, designers use this capacitor in smart thermostats, lighting, and wearables. Its performance supports both low- and moderately high-voltage circuits, making it versatile for many modern applications.

Engineers select this capacitor for projects that require dependable signal filtering, bypass, and decoupling.

0805G470KTE Capacitor STETCO SMD0805: Selection Tips

Choosing the Right Capacitor

Engineers should start by reviewing the voltage and capacitance requirements of their circuit. The 0805G470KTE capacitor STETCO SMD0805 offers a 47nF capacitance and a 50V rating, which fits many filtering and decoupling needs. Designers must check the tolerance and temperature range to match the application. For high-density boards, the SMD0805 package saves space and supports automated assembly. Always verify that the capacitor meets the necessary safety and environmental standards for the project.

Tip: Compare the capacitor’s dielectric class and insulation resistance with the circuit’s demands to ensure stable operation.

Integration Best Practices

Proper placement on the PCB improves performance. Place the capacitor as close as possible to the power supply pins of integrated circuits. This reduces noise and voltage spikes. Use short, wide traces to connect the capacitor, which lowers resistance and inductance. Tape and reel packaging allows for efficient pick-and-place assembly. During soldering, maintain the recommended temperature profile to avoid damaging the ceramic layers.

• Use the following checklist for integration:

  • Confirm correct polarity (if required)

  • Avoid excessive mechanical stress during mounting

  • Inspect solder joints for uniformity

Common Pitfalls

Some engineers overlook the effects of board layout on capacitor performance. Long traces can introduce unwanted resistance and inductance. Placing the capacitor too far from the load reduces its effectiveness. Excessive heat during soldering may crack the ceramic body. Always handle the 0805G470KTE capacitor STETCO SMD0805 with care to prevent chipping or breaking.

Note: Double-check the capacitor’s orientation and placement before reflow soldering to avoid costly rework.

The 0805G470KTE capacitor STETCO SMD0805 offers a compact design, stable performance, and strong reliability. Its RoHS compliance and halogen-free materials support safe and responsible manufacturing. Engineers can use this capacitor in many applications, from consumer electronics to industrial systems. For detailed specifications or design support, they should review the datasheet or contact STETCO’s technical team.

What does the "0805" in 0805G470KTE mean?

The "0805" refers to the capacitor’s size. It measures 0.08 inches long and 0.05 inches wide. This small size fits well on compact circuit boards.

Is the 0805G470KTE capacitor safe for the environment?

Yes. STETCO designed this capacitor to meet RoHS standards. It contains no hazardous substances and uses halogen-free materials. Manufacturers can use it in eco-friendly products.

Can engineers use this capacitor in automotive circuits?

Engineers often select this capacitor for automotive applications. It works well in dashboard circuits, infotainment modules, and other vehicle electronics. Its 50V rating and robust design support reliable operation.

How should engineers store and handle these capacitors?

• Store capacitors in a dry, cool place.

• Avoid dropping or bending them.

• Use tape and reel packaging for automated assembly.

• Handle with care to prevent chipping or cracking.

What is the main function of this capacitor in a circuit?

The 0805G470KTE capacitor filters signals, bypasses noise, and stabilizes voltage. It helps electronic devices run smoothly by reducing unwanted electrical interference.
