Discover the Amazing 6TPE330MAP Capacitor

The 6TPE330MAP capacitor, a product of Panasonic, is a notable component in the field of electronics. This Panasonic POLY 330UF 6.3V capacitor, also referred to as Tantalum - P, is a molded tantalum polymer capacitor featuring a capacitance of 330 µF and a voltage rating of 6.3 VDC. With a low impedance of 25 mOhm at 100 kHz, it ensures dependable performance. Designed for surface mount technology, the 6TPE330MAP integrates effortlessly into compact devices. Its epoxy resin body enhances durability, making it a favored choice for various electronic circuits.

Key Takeaways

The 6TPE330MAP capacitor features a high capacitance of 330 µF and a voltage rating of 6.3 VDC, making it ideal for stable power delivery in various electronic devices.
Its compact size (7343 metric package) allows for seamless integration into space-constrained gadgets like smartphones and tablets.
Constructed with a molded tantalum polymer design, the capacitor boasts a low equivalent series resistance (ESR) of 25 mOhm, enhancing efficiency in high-frequency applications.
The epoxy resin body provides excellent durability and environmental resistance, ensuring a long shelf life and reliable performance in demanding conditions.
The 6TPE330MAP is cost-effective, reducing the need for frequent replacements and simplifying manufacturing processes due to its compatibility with surface mount technology.
This capacitor is versatile, finding applications in consumer electronics, automotive systems, telecommunication, industrial equipment, and medical devices.
Being lead-free and RoHS compliant, the 6TPE330MAP aligns with modern environmental standards, making it a responsible choice for manufacturers.

Key Features of the 6TPE330MAP

Capacitance and Voltage Rating

The 6TPE330MAP capacitor stands out with its impressive capacitance of 330 µF. This high capacitance allows it to store a significant amount of electrical charge, making it ideal for applications requiring stable power delivery. The capacitor operates at a voltage rating of 6.3 VDC, which ensures compatibility with a wide range of electronic devices. This combination of capacitance and voltage rating makes the 6TPE330MAP a versatile component in various electronic circuits.

Physical Size and Form Factor

Designed for surface mount technology (SMT), the 6TPE330MAP features a compact 7343 metric package size. This small form factor, measuring 7.3 mm in length, 4.3 mm in width, and 1.8 mm in height, allows it to fit seamlessly into tight spaces within electronic devices. Its compact size makes it an excellent choice for modern gadgets where space is at a premium, such as smartphones and tablets.

Construction and Materials

The 6TPE330MAP is constructed using advanced materials that enhance its performance and durability. It features a molded tantalum polymer design, which provides a low equivalent series resistance (ESR) of 25 mOhm at 100 kHz. This low ESR improves the capacitor's efficiency in high-frequency applications. Encapsulated in an epoxy resin body, the capacitor exhibits high resistance to environmental stress, ensuring a long shelf life. Additionally, it is lead-free and RoHS compliant, aligning with modern environmental standards.

Benefits of the 6TPE330MAP

Reliability and Longevity

The 6TPE330MAP capacitor excels in reliability and longevity. Panasonic designed this component to withstand sustained voltage, ensuring consistent performance over time. Its epoxy resin body provides excellent protection against environmental stress, which contributes to its long shelf life. The use of tantalum, known for its stability, further enhances the capacitor's reliability. This makes the 6TPE330MAP a preferred choice in industries where durability is crucial, such as automotive and medical technology.

Performance Efficiency

Performance efficiency stands out as a key benefit of the 6TPE330MAP. With a low equivalent series resistance (ESR) of 25 mOhm at 100 kHz, this capacitor offers superior efficiency in high-frequency applications. The molded tantalum polymer design ensures low impedance, which enhances its ability to deliver stable power. This efficiency makes it ideal for use in power supply circuits and decoupling applications, where maintaining consistent performance is essential.

Cost-Effectiveness

The 6TPE330MAP also provides cost-effectiveness, making it an attractive option for various applications. Its long lifespan reduces the need for frequent replacements, which can save costs in the long run. Additionally, the capacitor's compatibility with surface mount technology (SMT) allows for easy integration into compact devices, reducing manufacturing complexity and costs. By offering a balance of performance and affordability, the 6TPE330MAP meets the needs of both budget-conscious and performance-driven projects.

Applications of the 6TPE330MAP

Consumer Electronics

The 6TPE330MAP capacitor plays a crucial role in consumer electronics. It provides stable power decoupling and filtering, essential for compact, high-frequency circuits found in devices like smartphones, tablets, and laptops. Its small form factor allows it to fit seamlessly into these portable gadgets, ensuring efficient energy storage and smooth voltage regulation. This makes it an indispensable component in the design of modern electronic devices.

Automotive Electronics

In the automotive industry, the 6TPE330MAP capacitor meets the demanding requirements of infotainment systems, electronic control units (ECUs), and advanced driver-assistance systems (ADAS). Its robust construction ensures stability and reliability, even in harsh automotive environments. The capacitor's ability to withstand sustained voltage and its long shelf life make it a preferred choice for automotive applications where durability is paramount.

Telecommunication Systems

Telecommunication systems benefit significantly from the 6TPE330MAP capacitor. It is ideal for signal filtering and power supply stabilization in high-speed networking and telecom equipment, such as routers, switches, and base stations. The capacitor's low equivalent series resistance (ESR) enhances its performance in these high-frequency applications, ensuring reliable operation and efficient power management in telecommunication infrastructures.

Industrial Applications

The 6TPE330MAP capacitor finds extensive use in industrial applications due to its robust performance and reliability. Industries rely on this capacitor for automation systems, including motor drivers and power supplies. Its low equivalent series resistance (ESR) of 25 mOhm at 100 kHz ensures efficient energy storage and smooth voltage regulation, which are crucial for maintaining the stability of industrial equipment. The capacitor's epoxy resin body provides excellent protection against environmental stress, making it suitable for demanding conditions. This durability ensures that industrial systems operate reliably, even under harsh conditions.

Medical Devices

In the medical field, the 6TPE330MAP capacitor plays a vital role in precision medical equipment. Medical devices require stable power supply filtering to ensure accurate and reliable operation. The capacitor's long shelf life and high resistance to sustained voltage make it an ideal choice for critical medical applications. Its compact size allows it to fit into small medical devices, providing the necessary power decoupling and filtering. This ensures that medical equipment functions efficiently, delivering precise results that are essential for patient care.

Embedded Systems

Embedded systems benefit significantly from the 6TPE330MAP capacitor. These systems often require components that can provide stable operation for microcontrollers and other digital integrated circuits. The capacitor's low impedance and high capacitance make it suitable for decoupling and bypass purposes in embedded circuits. Its small form factor allows it to integrate seamlessly into compact designs, ensuring efficient energy storage and smooth voltage regulation. This makes the capacitor an indispensable component in the design of modern embedded systems, supporting their reliable and efficient operation.

Comparing the 6TPE330MAP with Other Capacitors

Solid Tantalum vs. Ceramic Capacitors

Solid tantalum capacitors, like the 6TPE330MAP, offer distinct advantages over ceramic capacitors. They provide higher capacitance values in a smaller package, making them ideal for applications where space is limited. The 6TPE330MAP, with its 330 µF capacitance, exemplifies this benefit. Ceramic capacitors, on the other hand, typically offer lower capacitance values, which may not suffice for high-capacitance requirements.

Solid tantalum capacitors also exhibit superior performance in terms of stability and reliability. The 6TPE330MAP's low equivalent series resistance (ESR) of 25 mOhm at 100 kHz enhances its efficiency in high-frequency applications. Ceramic capacitors can suffer from microphonic effects, where mechanical vibrations cause changes in capacitance, potentially affecting circuit performance. The epoxy resin body of the 6TPE330MAP provides excellent protection against such environmental stresses, ensuring consistent performance.

Advantages Over Aluminum Electrolytic Capacitors

The 6TPE330MAP capacitor also holds several advantages over aluminum electrolytic capacitors. One significant benefit is its longer shelf life. The epoxy resin encapsulation of the 6TPE330MAP ensures durability and resistance to environmental factors, which contributes to its extended lifespan. Aluminum electrolytic capacitors, in contrast, may experience a shorter lifespan due to their liquid electrolyte, which can dry out over time.

Another advantage lies in the 6TPE330MAP's low ESR, which enhances its performance in high-frequency applications. This feature allows for efficient energy storage and smooth voltage regulation, making it suitable for power supply circuits and decoupling applications. Aluminum electrolytic capacitors often have higher ESR values, which can limit their efficiency in similar applications.

Additionally, the 6TPE330MAP is designed for surface mount technology (SMT), allowing for easy integration into compact devices. This feature reduces manufacturing complexity and costs, making it an attractive option for modern electronic designs. Aluminum electrolytic capacitors, typically larger and bulkier, may not fit as seamlessly into compact electronic devices.

Technical Specifications of the 6TPE330MAP

Tolerance and Temperature Range

The 6TPE330MAP capacitor exhibits a tolerance of ±20%, which ensures that it can accommodate slight variations in capacitance without affecting its performance. This tolerance level is crucial for maintaining the stability of electronic circuits, especially in applications where precise capacitance is necessary. The capacitor operates efficiently across a wide temperature range, making it suitable for various environments. It performs reliably in temperatures from -55°C to +105°C, ensuring consistent functionality even in extreme conditions. This broad temperature range enhances its versatility, allowing it to be used in diverse applications, from consumer electronics to industrial systems.

Equivalent Series Resistance (ESR)

The 6TPE330MAP stands out with its low equivalent series resistance (ESR) of 25 mOhm at 100 kHz. This low ESR is a significant advantage, as it minimizes energy loss and enhances the capacitor's efficiency in high-frequency applications. The reduced ESR allows the capacitor to deliver stable power, making it ideal for power supply circuits and decoupling applications. The low impedance also contributes to the capacitor's ability to handle high ripple currents, ensuring reliable performance in demanding electronic environments. This feature makes the 6TPE330MAP a preferred choice for applications requiring efficient energy storage and smooth voltage regulation.

Leakage Current

Leakage current is a critical parameter in capacitors, as it indicates the amount of current that leaks through the dielectric material when the capacitor is charged. The 6TPE330MAP capacitor features a low leakage current, which ensures minimal energy loss over time. This characteristic is essential for maintaining the efficiency and longevity of electronic circuits. The low leakage current also contributes to the capacitor's reliability, as it reduces the risk of circuit failure due to excessive energy loss. This makes the 6TPE330MAP an excellent choice for applications where energy efficiency and long-term reliability are paramount.

The 6TPE330MAP capacitor emerges as a pivotal component in modern electronics. Its high capacitance of 330 µF and low impedance of 25 mOhm at 100 kHz ensure reliable performance across various applications. The compact 7343 metric package size, combined with its epoxy resin encapsulation, enhances durability and longevity. This capacitor's design aligns with environmental standards, being lead-free and RoHS compliant. Its versatility makes it indispensable in consumer electronics, automotive systems, and industrial applications, underscoring its significance in today's technological landscape.

FAQ

What is the 6TPE330MAP capacitor?

The 6TPE330MAP is a molded tantalum polymer capacitor manufactured by Panasonic. It features a capacitance of 330 µF and a voltage rating of 6.3 VDC. This capacitor is designed for surface mount technology (SMT) applications, making it suitable for compact electronic devices.

Why is the 6TPE330MAP capacitor considered reliable?

Panasonic's 6TPE330MAP capacitor is known for its reliability due to its low impedance of 25 mOhm at 100 kHz and its epoxy resin encapsulation. This design ensures resistance to sustained voltage and environmental stress, contributing to a long shelf life.

What are the key benefits of using the 6TPE330MAP capacitor?

The 6TPE330MAP offers several benefits, including high performance in high-frequency applications, cost-effectiveness, and compatibility with modern electronic designs. Its low equivalent series resistance (ESR) enhances efficiency, while its long lifespan reduces the need for frequent replacements.

In which applications can the 6TPE330MAP capacitor be used?

The 6TPE330MAP capacitor is versatile and can be used in various applications, such as consumer electronics, automotive electronics, telecommunication systems, industrial applications, medical devices, and embedded systems. Its compact size and reliable performance make it suitable for these diverse fields.

How does the 6TPE330MAP compare to ceramic capacitors?

Solid tantalum capacitors like the 6TPE330MAP offer higher capacitance values in smaller packages compared to ceramic capacitors. They also provide superior stability and reliability, making them ideal for applications requiring high capacitance and consistent performance.

What advantages does the 6TPE330MAP have over aluminum electrolytic capacitors?

The 6TPE330MAP capacitor has a longer shelf life and lower ESR compared to aluminum electrolytic capacitors. Its epoxy resin encapsulation ensures durability, while its low ESR enhances performance in high-frequency applications. Additionally, its SMT design allows for easy integration into compact devices.

Is the 6TPE330MAP capacitor environmentally friendly?

Yes, the 6TPE330MAP capacitor is lead-free and RoHS compliant, aligning with modern environmental standards. This makes it a responsible choice for manufacturers looking to reduce their environmental impact.

What are the technical specifications of the 6TPE330MAP capacitor?

The 6TPE330MAP capacitor has a capacitance of 330 µF, a voltage rating of 6.3 VDC, and an impedance of 25 mOhm at 100 kHz. It operates efficiently across a temperature range from -55°C to +105°C and exhibits a tolerance of ±20%.

How does the 6TPE330MAP capacitor handle leakage current?

The 6TPE330MAP capacitor features a low leakage current, which minimizes energy loss over time. This characteristic ensures the efficiency and longevity of electronic circuits, making it a reliable choice for applications where energy efficiency is crucial.

Where can I purchase the 6TPE330MAP capacitor?

The 6TPE330MAP capacitor is available from various electronic component distributors. Prices may vary depending on the supplier and quantity, typically ranging from $0.79 to $40.00.
